this device made in China that can do what some do for software with Aircrack, Back Track, Troppix, WifiWay, wifislax, AirOSscript, works much like capturing packets to decrypt the key and takes approximately 1 hour depending on traffic, the good thing is you do not need to install any driver and does not depend on the hardware installed, costs approximately $ 130 and works WEP keys only for the moment, as the firmware is upgradeable later may also do so with the others. This device is very new about September 2010 and is the first version so hopefully in time we have a new version much more powerful for other types of keys.
the ANTCOR AW54-SC, a product that is sold in the market with trade names such as "Robin Fi."
Both products are manufactured by the company ANTCOR (disarming a wireless Robin see inscription inside ANTCOR).
use, appearance, functionality and compatible firmware is the same in both models.
access point very "special." We begin by discussing their main features and functions:
* Wi-Fi Bridge & # 160; & # 160; (Standard function)
* # & Access Point 160; & # 160; Function (standard) & # 160;
* & Universal Repeater # 160; , & # 160; (Special feature)
* Router (Firewall, UPnP, DDNS, DMZ, etc ...) & # 160; (standard feature)
* 3G Router (USB modem needs) & # 160; ; (Special Function)
* decrypt (WEP Wi-Fi-robin) & # 160; (special function) * Gui
to divest the antenna , & # 160; , & # 160; ;
* Good management interface (AirOs of ubiquitin) , & # 160; , & # 160; ; Output
* RP-SMA antenna, which allows us to easily extend their reach.
web 192.168.4.20 & Configuration # 160; user: admin & # 160; pass: admin & # 160;
wifi adapter for receivers with Ethernet. WIFI Network Auto Search function, Router, Access Point and repeater mode. Plug & play.
This adapter allows you to scan wireless networks wifi to it, hack wireless network and memorize selected for the next use. Once saved the network, the adapter will share the connection via its Ethernet port.
Disclaimer: this product should be used to perform network security audits themselves. "Weapons should be used to defend itself, although sometimes used to make war and take the oil to some countries"
Breaking the security of a third-party wireless network or nonprofit, is a crime . Robbing a bank also, but that the bank will charge interest from usury, not a crime.
- Features wireless adapter NET receivers. (Compatible with all satellite receivers)
- Protect your network from strangers
- Share your network with your friends
- Public Wireless Network Access at your fingertips
- Compatible with IEEE802.11b / g, using OFDM
- LCD Automatic search of the wireless signal without having to install software
- 5dBi antenna (can be extended with an antenna external high-gain) Upgradeable Firmware
- 1000 mW output power with a range of 2 kilometers
Specifications:
- Banda and channel
- 2,400 ~ 2.4835MHz
- 20dBm RF power output (software adjustable)
- Sensitivity-86dBm @ 11Mbps, PER \u0026lt;8%,-64dBm @ 54Mbps, PER \u0026lt;10%
- 11g speed automatic selection mode: 54/48/36/24/18/12/9/6Mbps
- Standards IEEE802.11g, IEEE802.11bIEEE 802.3u, IEEE 802.3af Supported Protocols
- CSMA / CA, TCP / IP, IPX / SPX, NetBEUI, PPPoE, DHCP, NDIS3, NDIS4, NDIS5
- MAC address (support Access Control) encryption
- Other 64 / 128/152bitsWEP Support for WPA, WPA2, 802.1x
- 1 10/100 BaseT LAN RJ45 1 USB USB
- 5VDC/2A & 5V/2A Power
- Working temperature -0 ~ 60
- Storage Temperature -20 ~ 70
- Humidity (non-condensing) 10% ~ 95% RH
- indoor antenna 5dBi omni-directional
- Size: 105 * 102 * 31
- Weight: 260 g
CONTENTS:
- 1 x ANTCOR AW54-SC
- 1 x 5 dBi antenna.
- 1 x RJ45 cable.
- 1 x USB Cable.
- 1 x Instruction Manual in Castilian.
Technically speaking:
The scheme is operating on 2 separate devices, but integrated.
On the one hand we have the router / ap and the other a charge of decoding circuit networks. Both devices share a memory address, in which exchange the digits of the key and the parameters of the network, so they can communicate and transfer data.
In laboratory tests have proven that the robin does not inject wifi network traffic, even if it manages to make a false association. If corrected this point in any revision of firmware, it would already perfect (also showing the pass in the display). This affects the time of audit. If there is traffic on it will be faster, and may be delayed if you're only on the network.
No results have been achieved wpa network, specifying that he found no customers for the handshake, but anyway for simple technical theories, could be very difficult to remove. Processor has no (theoretical 400mh) or storage for dictionaries needed to target these networks.
The only way in which we could give it a default key would be to generic.
Another common thing in these Chinese products is the fat rated. I read that was 2W, 1W etc ... several pages of vendors. The reality is that riding a mini-pci wireless card Dlink WMP-G09, which provides 20dBm output, equivalent to 100mW. The standard for a portable power is 15dBm, about 32 mW so the difference is remarkable, but only reached approximately the distance indicated in advertising with highly directional antennas cantenna type.
PROS: Easy
increased wireless coverage at home or connect devices without wireless features. Multiple options
operation.
* Small and lightweight.
* Useful for beginners wifi audits.
CONS:
very brief * Manual and automatic translation. * No traffic
injected in audits.
* Do not display the key in wifi-robin screen
* A single USB connector, so you have to use 3G to an external power adapter.
Conclusions:
tests already done, have been satisfactory. It is a good product, which even without the "wifirobin" is well worth the price tag. We just have to check the price of any repeater wifi, and just does that role. Wifi-robin brings more.
To continue, you're really routers with 3G support are not exactly cheap nor abundant in the market ... so it makes the price the product is adjusted to our point of view.
Recommended for those who want to expand or upgrade wireless connectivity of their consoles or lan in general (big houses, duplex, very thick walls or with many pipes etc. ...), For those who want to have an access point with advanced features or initiated in the audit wireless. There may be cheaper solutions to audit (Alfa usb and several distros), but none offers the versatility of wifirobin or ease of use (not counting card support, pc to live, namely a minimum of handling of unix shells etc. ...).
The possibilities wifirobin in order to use a wep network are very high, but the time varies considerably if a client connected or empty the net.
